The Intel® Core™ Desktop processors of the 14th generation named Raptor Lake-S bring a new chip layout with different CPU cores for various application scenarios. The Performance Cores provide power for compute-intensive applications, while the Efficiency Cores ensure energy efficiency under light loads. The Raptor Lake-S processors support PCIe Gen 5.0 and 4.0, DDR5 and DDR4. The processor is compatible with motherboards based on the Intel® 700 and 600 series chipsets.

Type Desktop

EAN 5032037278522

manufacturer number BX8071514900K

CPU type Core i9

Plinth 1700

Max. supported PCIe version 5.0

Core designation Core i9 14xxxK (Raptor Lake-S)

Number 24 Cores

Threads 32

Core type 1 Performance, 8 cores, 16 threads

Clock frequency Base clock 3.200 MHz, Boost clock 6.000 MHz

Core type 2 Efficiency, 16 cores, 16 threads

Clock frequency Base clock 2.000 MHz, Boost clock 4.200 MHz

AI core Unlocked Yes

Microarchitecture Raptor Lake-S

Cache Level 2: 32768 KB, Level 3: 36864 KB

Fan No fan included

Memory controller Supported ECC

Supported standards up to DDR4-2133, DDR4-2400, DDR4-2666, DDR4-2800, DDR4-2933, DDR4-3000, DDR4-3200, DDR5-4800, DDR5-5600

Graphics GPU Intel® UHD Graphics 770

Clock Standard: 300 MHz, Turbo: 1500 MHz

Power consumption (TDP) 125 watts

max. power consumption (TDP) 253 watts

Note Boxed version without cooler
