Power
Total power 1200 W
Combined current (+12V) 1200 W
AC input voltage 100 - 240 V
Input current 15 - 8 A
Combined current (+3.3V) 100 W
Efficiency 92%
Max. output current (+5Vsb) 3 A
Max. output current (+3.3V) 20 A
Combined current (+5V) 100 W
Max. output current (-12V) 0.4 A
Max output current (+5V) 20 A
Power protection features Overcurrent, Overload, Overvoltage, Overheating, Short circuit, Undervoltage
Max. output current (+12V1) 100 A
AC input frequency 50/60 Hz
Connections and interfaces
PCI Express connector Yes
Number of Molex connectors 4pin 4
Peripheral (Molex) power cable length 150,450 mm
CPU power cable length 70 cm
PCI Express power connectors (12+4-pin) cable length 600 mm
CPU connector (4+4 pin) Yes
Motherboard connector 20+4 pin ATX
PCI Express power connectors (12+4 pin) 1
Number of SATA power connectors 8
Cable type Fully modular
SATA power cable length 150,450 mm
Power cable length motherboard 60 cm
Number of PCI Express power connectors 6+2pin 3
Performance 80 Plus certification
80 PLUS Platinum ATX version 3.1
Purpose
PC power supply unit (PSU) form factor
ATX Mean time between failures (MTBF)
100000 h Design
Cooling Active
Number of fans 1 fan
Fan diameter 13.5 cm
Power switch Yes
Product color Black
Fan placement Top
Operating conditions
Operating temperature 0 - 50 °C
Package contents
Included cables AC
Weight and dimensions
Height 86 mm
Depth 150 mm
Width 150 mm
Packaging data
Packaging depth 330 mm
Packaging type Box
Packaging height 130 mm
Packaging width 195 mm
User manual Yes
Package weight 2.78 kg
Other features
Screws included Yes
Number of screws 4
Cable ties included Yes
